Name:
JL686A
Model:
HPE Aruba JL686A#ABA
Detail:
HPE Networking Instant On Switch Series 1930 48-Port Gb Smart-Managed Layer 2+ Ethernet Switch | 48x 1G | 4X SFP+ | 48x CL4 PoE 370W | US Cord (JL686A#ABA)
Condition:
New
Price:
Original price was: $987.00.$869.00Current price is: $869.00.
Warranty:
Quantity:
Shipping:
Payment:
24/7 Online Service
+1 (512) 885-5387
info@jazzcybershield.com
30 Days Return & Refund
You may return a product within 30 days of the delivery date and the proccessing time is 15 days.
Best Price Guarantee
Found it cheaper? Let us know! We're committed to offering the lowest prices around.
Product Detail
- The Aruba Instant On 1930 48G 4SFP/SFP+ Switch is a high performance, smart managed switch designed for small and medium businesses – fast set-up, easy management, security you can trust.
- Functionality: high performance, advanced features, and top security made simple – Gigabit wirespeed performance. Feature-rich to fit into most networking enviroments. Built-in security protects your network from external threats by blocking malware attacks and keeping unauthorised users off the network.
- Configuration: Rack-width design with rack mounting ears. Or place desktop or flat surface. Ports and LEDs facing the front – #ACC w/ internal power supply and UK-style plug. Fanless silent operation.
- Management: Simplified cloud management from app or web browser with no recurring cost – The Aruba Instant On mobile app allows you to set up, manage, and monitor Instant On switches and Access Points directly from your phone, from anywhere. Guided step-by-step instructions to install devices to get your network up and running quickly – no technical expertise required. Alternative integrated traditional full local web interface for advanced configuration with static routing, ACLs, SNMP.
- Ports: 52 active ports | 48x Gigabit 10/100/1000 + 4x Gigabit / 10G SFP+ slots| High-performance future-proof switch.
The HPE Aruba Instant On 1930 48G 4SFP/SFP+ Switch is a versatile and easy-to-manage Layer 2+ switch designed for small and medium-sized businesses. It offers 48 Gigabit Ethernet ports, allowing you to connect a large number of devices to your network. With four SFP/SFP+ ports, you can also connect to fiber optic networks for greater bandwidth and distance. The switch’s intuitive web-based interface makes it simple to configure and monitor your network, even for users without extensive technical expertise.
JL686A Specification | |
| I/O ports and slots | 48 RJ-45 autosensing 10/100/1000 Class 4 PoE ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASETX, IEEE 802.3ab Type 1000BASE-T); Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only
4 SFP+ 1/10GbE ports |
| Dimension | 17.42(w) x 12.7(d) x 1.73(h) in (44.25 x 32.26 x 4.39 cm) (1U height) |
| Processor and memory | ARM Cortex-A9 @ 800 MHz, 512 MB SDRAM, 256 MB flash; packet buffer: 1.5 MB |
| Throughput (Mpps) | 130.95 Mpps |
| Switching capacity | 176 Gbps |
| Operating temperature | 32°F to 104°F (0°C to 40°C) |
| Operating relative humidity | 15% to 95% @ 104°F (40°C) |
| Nonoperating/Storage temperature | -40°F to 158°F (-40°C to 70°C) |
| Nonoperating/Storage relative humidity | 15% to 95% @ 140°F (60°C) |
| Altitude | up to 10,000 ft (3 km) |
| Idle power | 34.5 W |
| PoE | 370 W Class 4 PoE |
| Power Supply | Internal power supply |
